011: NT50B1 safety breaker with board is used as a protection switch for power supplying a circuit with AC 50/60Hz, rated voltage 230V, current from 6A to 32A. The breaker with stable overload protection function, is suitable for lighting devices in houses and public buildings. It conforms with standard of IEC60898.
Main technical
Rated current In | 10A, 15A, 20A, 30A |
Pole number | 2P |
Rated voltage Ue | AC230V |
Rated frequency | 50Hz |
Rated overload breaking capacity | 1.5KA |
Rated shock withstand volt | 4KV |
High-voltage insulation | 2ka/1min |
Mechanical life | 10000 times |
Electrical life | 8000 times |
Protection level | IP20 |
Ambient temperature | -5℃ to +℃ |
Terminal wiring capacity | 2.5mm |
