GV2 / GV2-ME series motor protector are mainly used for the overload and short circuit protection of motor in AC 50/60Hz,up to 660V,0.1-80A power circuit,as a full-voltage starter to start and cut off the motor,under the AC3 load or for the overload and short circuit protection of the circuit and power equipment in the power distribution network.
Application
Model | GV2-ME |
Rated voltage | 230/400V |
Rated current | 24-32A |
Poles | 3 |
Network type | AC |
Control type | (Press type) button |
Frequency | 50/60Hz |
Mounting | Rail mounting |
Standard | IEC/EN 60947-2 |
Model | Rated Current(A) |
GV2-M01 | 0.1-0.16 |
GV2-M02 | 0.16-0.25 |
GV2-M03 | 0.25-0.4 |
GV2-M04 | 0.4-0.63 |
GV2-M05 | 0.63-1 |
GV2-M06 | 1-1.6 |
GV2-M07 | 1.6-2.5 |
GV2-M08 | 2.5-4 |
GV2-M10 | 4-6.3 |
GV2-M14 | 6-10 |
GV2-M16 | 9-14 |
GV2-M20 | 13-18 |
GV2-M21 | 17-23 |
GV2-M22 | 20-25 |
GV2-M32 | 24-32 |
